DS004
Rotary Tiller
Specifications
| Gear Ratio | 1,93:1 |
| Input Speed | 540 rpm |
| Output Speed | 279 rpm |
| Input Power | 65 HP / 48 kW |
| Output Torque | 1610 Nm |
| Oil Grade | SAE 90 / SAE 140 |
| Oil Volume | 3 Lt. |
| Usage Area | Rotary Tiller |
| L = Producible according to the your request | |
| Fixed Rotary Tiller | |
| Working Width | L |
| 155 cm | 790 mm |
| 180 cm | 915 mm |
| 210 cm | 1040 mm |
| 240 cm | 1165 mm |
| Hydraulic Side Shifting Rotary Tiller | |
| Working Width | L |
| 155 cm | 683 mm |
| 180 cm | 683 mm |
| 210 cm | 808 mm |
| 240 cm | 808 mm |
