Homepage >DS504 Snowblower

DS504
Snowblower

Gearboxes of Land Preparation Machine
DS504

Snowblower

Product Document

Specifications

Gear Ratio 40:1
Input Speed 540 rpm
Output Speed 14 rpm
Input Power 10 HP / 7 kW
Output Torque 3150 Nm
Oil Grade SAE 90 / SAE 140
Oil Volume 0,50 Lt.
Weight 19 kg
Usage Area Snowblower



Technical Drawing
DS504
Snowblower

Snowblower Technical Drawing

Gear Arrangement
DS504
Snowblower

Snowblower Gear Arrangement
